RVM – groove connector machine
RVM – groove connector machine is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Profile your groove connectors flexibly and according to your needs. Save high costs and a lot of time!
- Smooth hand crank
- Compact design and low weight thanks to clever material mix
- Suitable for all coated and uncoated sheets
- Optimal geometry: the wider center bar on the groove connector ensures better water drainage and an even better look!
Technical data
Article name: | RVM – groove connector machine | |
Article number: | FS-RVM-01 | |
Weight: | approx. 7 kg | |
L/W/H: | 315/325/145 mm | |
Insertion width (roll width): | 250 mm | |
Sheet thicknesses: |
Aluminum, zinc, copper: up to 1.0mm Vz. Stbl.: up to 0.75mm Stainless steel: up to 0.6mm |
|
Operating instructions: | download here | |
advertising leaflet: | Article name: | gearbox adapter-retrofit kit |
Article number: | FS-GA-Kit-01 | |
Weight: | approx. 1.6 kg | |
L/W/H: | 340 / 85 / 140 mm |
